Spectroscopy systems
HARPIA-LIGHT
Compact transient absorption spectrometer
A compact transient-absorption instrument with continuous scan mode for day-to-day ultrafast spectroscopy on a small bench.
Features
- Compact single-box TA spectrometer
- Continuous scan mode
- High-repetition-rate Yb pumps
- Automated acquisition software
- Bench-scale ultrafast spectroscopy
Used in
Specifications
| Model | HARPIA-LIGHT |
|---|---|
| Measurement capabilities | |
| Modes | Transmission and reflection |
| Probe spectral range | 435 – 935 nm |
| Probe polarization control | Linear (0 – 180°) |
| Pump wavelengths | 515 nm, 343 nm |
| Delay range (resolution) | 7.5 ns (10 fs) |
| Temporal resolution | ≤ 290 fs |
| Laser repetition rate | 60 kHz 1) |
| Environmental & utility requirements | |
| Operating temperature | 17 – 26 °C |
| Relative humidity | < 80% (non-condensing) |
| Electrical requirements | 100 V AC, 3 A – 240 V AC, 1.3 A; 50 – 60 Hz |
- Pulse selection can be set to any integer division of the 60 kHz fundamental repetition rate.
