Evaporation sources
KT-KC
Knudsen effusion cell
Knudsen effusion cells in low-, standard-, and high-temperature variants. Each range uses a dedicated filament and heat-shield stack to keep the flux stable and limit chamber-wall heating.
Features
- Rated for UHV
- PBN, Al₂O₃, or W crucibles
- Water-cooled sleeve
- Manual or motorized shutter
- Optional programmed control
Specifications
| Parameter | Value |
|---|---|
| Low temperature (LT) | |
| Mounting flange | DN40CF |
| Filament | Ta |
| Working temperature | 100–1000 °C |
| Temperature stability | ±0.1 °C |
| Cooling | Water |
| Thermocouple | K |
| Crucible volume | 1.5–10 cc |
| Bake temperature | 200 °C |
| Standard (ST) | |
| Mounting flange | DN40CF |
| Filament | Ta |
| Working temperature | 700–1400 °C |
| Temperature stability | ±0.1 °C |
| Cooling | Water |
| Thermocouple | C |
| Crucible volume | 1.5–10 cc |
| Bake temperature | 200 °C |
| High temperature (HT) | |
| Mounting flange | DN40CF |
| Filament | W |
| Working temperature | 1200–1900 °C |
| Temperature stability | ±0.1 °C |
| Cooling | Water |
| Thermocouple | C |
| Crucible volume | 1.5–10 cc |
| Bake temperature | 200 °C |
